• 24-inch plate
• 60 x 60 mm square bar; square bar is guided by rollers
• Hexagonal bar has a thickness of 41mm, adjustable hex bar, vertical column with reinforced base
• Working range of the bead breaker shovel: 17"
• Cylinder diameter 200 mm/piston 25 mm
• Working range 12"/17''
• Pedals are positioned in a row (including rotary control); pedal unit can be detached for servicing work
• Infinitely variable inverter: 0/16 rpm
• Clamping cylinder diameter 80mm
• External clamping claws can be easily replaced,
• Complete with HPX-Advance and helper arm

Brochure Download

	Megamount 50FWS	Megamount 70FWS
Power supply	230V/50Hz/1ph - 1 speed	230V/50Hz/1ph - Variable speed with Inverter
Compact Turntable 12"-27" (12"-24"/14"-27")	✔	—
Flex Turntable 10"-27" (10"-24"/12"-27")	—	✔
Manual positioning of tool arm	✔	—
Pneumatic positioning of tool arm	—	✔
Inflating Gun	—	—
Pedal-operated inflating device	✔	✔
Lateral tool holder	✔	✔
Roller board	✔	✔
Pedal-operated bead-breaker	✔	—
Bead-breaker control on the shovel lever	—	✔
Helping Device	WS	WS
Complete set of plastic protections	✔	✔
Quick change head	—	✔
